*All dimensions are nominal

Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)

CC1101RTKR VQFN RTK 20 3000 338.1 338.1 20.6

PACKAGE MATERIALS INFORMATION

www.ti.com 10-Oct-2012

Pack Materials-Page 2
