Texas Instruments CC1101 User Manual

CC1101
SWRS061H Page 69 of 98
Address
Register
Description
Details on page number
0x30 (0xF0)
PARTNUM
Part number for CC1101
92
0x31 (0xF1)
VERSION
Current version number
92
0x32 (0xF2)
FREQEST
Frequency Offset Estimate
92
0x33 (0xF3)
LQI
Demodulator estimate for Link Quality
92
0x34 (0xF4)
RSSI
Received signal strength indication
92
0x35 (0xF5)
MARCSTATE
Control state machine state
93
0x36 (0xF6)
WORTIME1
High byte of WOR timer
93
0x37 (0xF7)
WORTIME0
Low byte of WOR timer
93
0x38 (0xF8)
PKTSTATUS
Current GDOx status and packet status
94
0x39 (0xF9)
VCO_VC_DAC
Current setting from PLL calibration
module
94
0x3A (0xFA)
TXBYTES
Underflow and number of bytes in the TX
FIFO
94
0x3B (0xFB)
RXBYTES
Overflow and number of bytes in the RX
FIFO
94
0x3C (0xFC)
RCCTRL1_STATUS
Last RC oscillator calibration result
94
0x3D (0xFD)
RCCTRL0_STATUS
Last RC oscillator calibration result
95
Table 44: Status Registers Overview
Table 45: SPI Address Space (see next page)
