0x1F: WOREVT0 –Low Byte Event0 Timeout
Bit
Field Name
Reset
R/W
Description
7:0
EVENT0[7:0]
107 (0x6B)
R/W
Low byte of EVENT0 timeout register.
The default EVENT0 value gives 1.0s timeout, assuming a 26.0 MHz crystal.
0x20: WORCTRL – Wake On Radio Control
Bit
Field Name
Reset
R/W
Description
7
RC_PD
1
R/W
Power down signal to RC oscillator. When written to 0, automatic initial
calibration will be performed
6:4
EVENT1[2:0]
7 (111)
R/W
Timeout setting from register block. Decoded to Event 1 timeout. RC oscillator
clock frequency equals F
XOSC
/750, which is 34.7 – 36 kHz, depending on
crystal frequency. The table below lists the number of clock periods after
Event 0 before Event 1 times out.
Setting
t
Event1
0 (000)
4 (0.111 – 0.115 ms)
1 (001)
6 (0.167 – 0.173 ms)
2 (010)
8 (0.222 – 0.230 ms)
3 (011)
12 (0.333 – 0.346 ms)
4 (100)
16 (0.444 – 0.462 ms)
5 (101)
24 (0.667 – 0.692 ms)
6 (110)
32 (0.889 – 0.923 ms)
7 (111)
48 (1.333 – 1.385 ms)
3
RC_CAL
1
R/W
Enables (1) or disables (0) the RC oscillator calibration.
2
R0
Not used
1:0
WOR_RES
0 (00)
R/W
Controls the Event 0 resolution as well as maximum timeout of the WOR
module and maximum timeout under normal RX operation:
Setting
Resolution (1 LSB)
Max timeout
0 (00)
1 period (28 – 29 μs)
1.8 – 1.9 seconds
1 (01)
2
5
periods (0.89 – 0.92 ms)
58 – 61 seconds
2 (10)
2
10
periods (28 – 30 ms)
31 – 32 minutes
3 (11)
2
15
periods (0.91 – 0.94 s)
16.5 – 17.2 hours
Note that WOR_RES should be 0 or 1 when using WOR because WOR_RES >
1 will give a very low duty cycle.
In normal RX operation all settings of WOR_RES can be used.
