4.2 J721E EVM Interface Mapping
Table 4-1 shows the J721E EVM Interface Mapping table.
Table 4-1. J721E EVM Interface Mapping
Interface Name Port on SoC Device Part Number
Memory – LPDDR4 DDR0 MT53D1024M32D4DT
Memory – OSPI MCU_OSPI0 MT35XU512ABA1G12-0SIT
(Channel B of 1:2 Mux TS3DDR3812RUAR)
Memory – Hyper Flash MCU_OSPI0 S71KS512SC0BHV000
(Channel C of 1:2 Mux TS3DDR3812RUAR)
Memory – Quad SPI MCU_OSPI1 MT25QU512ABB8E12-0SIT
Memory – eMMC MMC0 MTFC16GAPALBH-AAT ES
Memory – Micro SD Socket MMC1 DM3BT-DSF-PEJS
Memory – UFS UFS0 THGAF8G8T23BAIL
Memory – Board ID EEPROM WKUP_I2C0
(I2C6 for CSI Expansion)
CAT24C256WI-GT3
(CAV24C256WE-GT3 for J721E SOM)
Memory – Boot EEPROM MCU_I2C0 AT24CM01
Ethernet – RGMII MCU_RGMII1 DP83867ERGZT
Ethernet – Quad SGMII SERDES0 (SGMII2) VSC8514XMK
USB – 3.1 Type C + PD + CC Controller SERDES3 (USB0) 2012670005 + PTPS25830QWRHBTQ1 +
TUSB321RWBR
USB – 2.0 (HUB) USB1 TUSB4041IPAPR
Display Port SERDES4 (DP0) 472720001
FPD Link Panel Serializer DSI0 PDS90UB941ASRTDTQ1
FPD Link Radio Tuner McASP11 DS90UB926QSQE
Audio Codec McASP10 PCM3168APAP
PCIe – x4 Lane Socket (x1 Lane) SERDES0 (PCIe0) 10142333-10111MLF
PCI2 – x4 Lane Socket (x2 Lane) SERDES1 (PCIe1) 10142333-10111MLF
PCIe – M.2 Socket (M-Key 2280) SERDES2 (PCIe2) MDT320M01001
MLB/MLBP expansion MLB0 QSH-020-01-L-D-DP-A-K
UART Terminal (UART-to-USB) UART [0:2] & 4 FT4232HL
UART Terminal (UART-to-USB) WKUP_UART0 & MCU_UART0 FT2232HL
CAN (4x) MCU_MCAN0 TCAN1043-Q1 (W/ Wake function)
MCU_MCAN1 TCAN1042HGVD
MCAN0 TCAN1043-Q1 (W/ Wake function)
MCAN2 TCAN1042HGVD
ADC Header MCU_ADC0 TSW-110-07-S-D
J721E EVM Hardware Architecture www.ti.com
28 Jacinto7 J721E/DRA829/TDA4VM Evaluation Module (EVM) SPRUIS4D – MAY 2020 – REVISED MARCH 2022
