Table 4-33 and Table 4-34 lists the CSI expansion connector pinouts.
Table 4-33. CSI Expansion Connector J52 Pinout
CSI2 Connector Interface J52
Pin No Signal Pin No Signal
1 VCC_12V0 21 CSI0_RX3_P
2 CSI2_I2C_SCL_DV 22 CSI2_A_GPIO4_DV
3 VCC_12V0 23 CSI0_RX3_N
4 CSI2_I2C_SDA_DV 24 DGND
5 CSI0_RXCLK_P 25 CSI1_RXCLK_P
6 CSI2_A_GPIO0_DV 26 CSI1_RX3_P
7 CSI0_RXCLK_N 27 CSI1_RXCLK_N
8 CSI2_A_GPIO1_DV 28 CSI1_RX3_N
9 CSI0_RX0_P 29 CSI1_RX0_P
10 CSI2_A_REFCLK_DV 30 EXP_3V3
11 CSI0_RX0_N 31 CSI1_RX0_N
12 DGND 32 EXP_3V3
13 CSI0_RX1_P 33 CSI1_RX1_P
14 CSI2_RSTZ_DV 34 EXP_3V3
15 CSI0_RX1_N 35 CSI1_RX1_N
16 DGND 36 EXP_3V3
17 CSI0_RX2_P 37 CSI1_RX2_P
18 CSI2_A_GPIO2_DV 38 VCC_CSI_IO
19 CSI0_RX2_N 39 CSI1_RX2_N
20 CSI2_A_GPIO3_DV 40 VCC_CSI_IO
Table 4-34. CSI Expansion Connector J48 Pinout
CSI2 Connector Interface J48
Pin No Signal Pin No Signal
1 VCC_12V0 21 CSI2_RX3_P
2 CSI2_I2C_SCL_DV 22 CSI2_B_GPIO4_DV
3 VCC_12V0 23 CSI2_RX3_N
4 CSI2_I2C_SDA_DV 24 DGND
5 CSI2_RXCLK_P 25 NC
6 NC 26 NC
7 CSI2_RXCLK_N 27 NC
8 CSI2_B_GPIO1_DV 28 NC
9 CSI2_RX0_P 29 NC
10 CSI2_B_REFCLK_DV 30 EXP_3V3
11 CSI2_RX0_N 31 NC
12 DGND 32 EXP_3V3
13 CSI2_RX1_P 33 NC
14 CSI2_RSTZ_DV 34 EXP_3V3
15 CSI2_RX1_N 35 NC
16 DGND 36 EXP_3V3
17 CSI2_RX2_P 37 NC
18 CSI2_B_GPIO2_DV 38 VCC_CSI_IO
19 CSI2_RX2_N 39 NC
20 CSI2_B_GPIO3_DV 40 VCC_CSI_IO
J721E EVM Hardware Architecture www.ti.com
82 Jacinto7 J721E/DRA829/TDA4VM Evaluation Module (EVM) SPRUIS4D – MAY 2020 – REVISED MARCH 2022
Submit Document Feedback
Copyright © 2022 Texas Instruments Incorporated
