Page #37 background imageLoading...
Page #37 background image
3
1
2
QN1
CS D15380F3
3
1
2
QN2
CS D15380F3
3
1
2
QP 1
CS D25480F3
3
1
2
QP 2
CS D25480F3
GND GND
751_SBU1 751_S BU2
GP IO _P F
GP IO _NF
LDO_3V3
249k
R102
CRCW0402249KFKED
249k
R101
CRCW0402249KFKED
1.00M
R103
CRCW040 21M00FKED
1.00M
R104
CRCW040 21M00FKED
GP IO _P F
GP IO _NF
751_SBU2751_SBU1
Liquid Detection
Figure 5-5. Liquid Detection Schematic
www.ti.com Hardware Design Files
SLVUCP9A – NOVEMBER 2023 – REVISED MARCH 2024
Submit Document Feedback
TPS25751 Evaluation Module 37
Copyright © 2024 Texas Instruments Incorporated
