Texas Instruments TPS25751EVM User Manual

5.3 Bill of Materials (BOM)
Table 5-1 lists the bill of materials for TPS25751EVM.
Table 5-1. Bill of Materials
Designator Quantity Value Description
Package
Reference
Part Number Manufacturer
Alternate Part
Number
Alternate
Manufacturer
!PCB1 1 Printed Circuit Board IPP009 Any
C1, C8, C24,
C32, C33
5 0.1uF CAP, CERM, 0.1uF, 35V, +/- 10%,
X5R, 0402
0402 GMK105BJ104KV-F Taiyo Yuden
C2, C3, C4, C5,
C18, C19, C20,
C21, C46, C47,
C48, C49
12 0.01uF CAP, CERM, 0.01uF, 50V, +/- 5%,
X7R, 0402
0402 C0402C103J5RACTU Kemet
C6, C7 2 1uF CAP, CERM, 1uF, 35V, +/- 10%,
X5R, 0402
0402 GRM155R6YA105KE11D MuRata
C9, C10, C11,
C12, C13
5 10uF CAP, CERM, 10uF, 35V, +/- 20%,
X5R, 0603
0603 GRM188R6YA106MA73D Murata
C14, C15, C28,
C29
4 330pF CAP, CERM, 330pF, 50V, +/-
10%, X7R, AEC-Q200 Grade 1,
0201
0201 CGA1A2X7R1H331K030BA TDK
C16, C17, C23,
C25, C26
5 10uF CAP, CERM, 10uF, 10V, +/- 20%,
X5R, 0402
0402 CL05A106MP5NUNC Samsung Electro-
Mechanics
C22 1 4.7uF CAP, CERM, 4.7uF, 50V, +/- 10%,
X5R, 0805
0805 C2012X5R1H475K125AB TDK
C27, C45, C51,
C60, C65, C68
6 1uF CAP, CERM, 1uF, 16V, +/- 10%,
X6S, 0402
0402 C1005X6S1C105K050BC TDK
C30, C31 2 22uF CAP, CERM, 22uF, 35V, +/- 20%,
X5R, 0805
0805 C2012X5R1V226M125AC TDK
C34, C35, C36,
C37, C40, C42
6 0.1uF CAP, CERM, 0.1uF, 10V, +/- 10%,
X5R, 0201
0201 CL03A104KP3NNNC Samsung Electro-
Mechanics
C39, C41 2 4.7uF CAP, CERM, 4.7uF, 6.3V, +/-
20%, X5R, 0201
0201 GRM035R60J475ME15D MuRata
C43, C44 2 10pF CAP, CERM, 10pF, 16V,+/- 10%,
C0G, 0402
0402 C0402C100K4GACTU Kemet
C50 1 1uF CAP, CERM, 1µF, 50V,+/- 20%,
X5R, AEC-Q200 Grade 3, 0603
0603 CGA3E3X5R1H105M080AB TDK
C52, C53, C54,
C55, C56, C57,
C58, C59
8 0.1uF CAP, CERM, 0.1uF, 50V, +/- 10%,
X7R, AEC-Q200 Grade 1, 0402
0402 CGA2B3X7R1H104K050BB TDK
C64 1 2.2uF CAP, CERM, 2.2uF, 16V, +/- 10%,
X6S, 0402
0402 C1005X6S1C225K050BC TDK
www.ti.com Hardware Design Files
SLVUCP9A – NOVEMBER 2023 – REVISED MARCH 2024
Submit Document Feedback
TPS25751 Evaluation Module 43
Copyright © 2024 Texas Instruments Incorporated
