Table 5-1. Bill of Materials (continued)
Designator Quantity Value Description
Package
Reference
Part Number Manufacturer
Alternate Part
Number
Alternate
Manufacturer
C66 1 4.7uF CAP, CERM, 4.7uF, 100V, +/-
10%, X7S, 1210
1210 C3225X7S2A475K200AE TDK
C67 1 0.47uF CAP, CERM, 0.47uF, 100V, +/-
10%, X7S, 0805
0805 C2012X7S2A474K125AB TDK
C69 1 0.47uF CAP, CERM, 0.47uF, 10V, +/-
10%, X5R, 0402
0402 GRM155R61A474KE15D MuRata
C70 1 220uF CAP, TA, 220uF, 16V, +/- 20%,
0.1 ohm, SMD
7343-43 TPSE227M016R0100 AVX
C71 1 0.47uF CAP, CERM, 0.47uF, 50V, +/-
10%, X7R, 0603
0603 C1608X7R1H474K080AC TDK
C72 1 15pF CAP, CERM, 15pF, 100V,+/- 5%,
C0G/NP0, 0201
0201 GRM0335C2A150JA01D MuRata
D1, D2, D3, D4,
D11
5 Blue LED, Blue, SMD LED_0603 150060BS75000 Wurth Elektronik
D5, D6, D7, D9 4 White LED, White, SMD 0402, White LW QH8G-Q2S2-3K5L-1 OSRAM
D8 1 Red LED, Red, SMD LED_0603 150060RS75000 Wurth Elektronik
D10 1 20V Diode, Schottky, 20V, 0.5A,
SOD-123
SOD-123 MBR0520LT1G ON Semiconductor
H2, H3, H4, H5 4 Machine Screw, Round, #4-40 x
1/4, Nylon, Philips panhead
Screw NY PMS 440 0025 PH B&F Fastener Supply
H7, H8, H10,
H11
4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1
1
Header, 100mil, 3x2, Tin, TH 3x2 Header PEC03DAAN Sullins Connector
Solutions
J2, J3, J4 3 Receptacle, USB 3.1 Type C,
R/A, Gold, SMT
Receptacle, USB
3.1 Type C, R/A,
SMT
DX07S024JJ2R1300 JAE Electronics
J6 1 Header, 100mil, 15x2, Gold, TH TH, 30-Leads,
Body 1500x200mil,
Pitch 100mil
TSW-115-08-L-D Samtec
J7 1 CONN_SSL_SOCK
ET5
2.09159E+14 KYOCERA AVX
J11 1 Header, 100mil, 4x2, Gold, TH 4x2 Header TSW-104-07-G-D Samtec
J12 1 Header, 2.54mm, 4x1, Gold, TH Header, 2.54mm,
4x1, TH
350-10-104-00-006000 Mill-Max
J13, J14, J16 3 Header, 100mil, 2x1, Gold, TH Sullins 100mil, 1x2,
230 mil above
insulator
PBC02SAAN Sullins Connector
Solutions
Hardware Design Files www.ti.com
44 TPS25751 Evaluation Module SLVUCP9A – NOVEMBER 2023 – REVISED MARCH 2024
Submit Document Feedback
Copyright © 2024 Texas Instruments Incorporated
