Textron Aviation 680A - Page 86

Page 513
25-20-00
MB680
Martin-Baker
MISSION SEAT ETSO
MAINTENANCE MANUAL
Fig. 1 Locking plungers
MBI21463-01
A
A
A A
0.250 INCHES (6.35mm)
MAXIMUM
LOCKING PLUNGER RETRACTED
0.440 INCHES (11.18mm)
MINIMUM
LOCKING PLUNGER EXTENDED
ICA-680A-25-80003A
Sep 4/2020
