1.11: SUPPORTS & CONNECTIONS
For details on Supports & Connections, see Support & Connections IOM (#1200485) at
https://www.tgw-conveyor.com/support/iom-manuals/supports-and-connections
1.12: ENVIRONMENT
Temperature range (ambient):
+35° to +120°F. For applications that exceed this temperature range, please consult Applications
Engineering.
Oily or Wet Conditions:
Will impair frictional drive characteristics.
Corrosive or Abrasive Substances:
Will adversely affect various components
1.13: COMPONENT ORIENTATION
Using your conveyor system layout drawing and the numbers on the I.D. tags of each component
position and orient the conveyor section.
You must know:
• The direction of product flow
• The elevation height
• How the drive is positioned
• Charge and discharge end beds
IMPORTANT! Do not make alterations to the equipment without consulting with user’s representative
and TGW Systems. Unauthorized modifications to the equipment may impair its functions, create a
hazardous condition, affect its useful life and /or void the warranty.
