NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 74 of 129
1.38: JUMPER DESCRIPTIONS
Table 6: Jumper Descriptions
Jumper Descriptions
JP1 Downstream slug control
Pins 1-2 = slug pass through
Pins 2-3 = slug interrupt
Pins 3-4 = slug interrupt
Pins 4-5 = singulation to slug crossover
Pins NC = slug interrupt
JP2 Upstream slug control
Pins 1-2 = slug pass through
Pins 2-3 = slug interrupt
Pins NC = slug interrupt
JP3 Release control at TB1
Pins 1-2 = single release
Pins 2-3 = logic interrupt
Pins NC = pulsed released
JP4 Release control at TB4
Pins 1-2 = single release
Pins 2-3 = logic interrupt
Pins NC = zone status input (determined by JP5)
JP5 Zone Status control (JP5 only available on full function module)
Pins 1-2 or NC = downstream logic status
Pins 2-3 = downstream sensor status
