TGW NBC - Belt Welding Instructions

NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 31 of 129
NBC, NITTA BELT WELDING INSTRUCTIONS
NBC, TGW Nitta Belt Welding Instruction.
To rent or purchase parts contact TGW Lifetime Services at 231-
798-4547.
TGW Nitta Belt Weld Instruction Manual #1120515 -
https://www.tgw-conveyor.com/support/iom-manuals/nbc-manual
TGW Nitta Belt Weld Instruction Maintenance Video -
https://www.tgw-conveyor.com/media-center/maintenance-
videos/82-belt-driven-live-roller
TGW Nitta Belt Welder Press Rental Kit:
It e m #
Description
1207112
TOOL,NBC-NITTA-RENTAL-WELDER KIT-FULL
It e m #
Description
1211171
CASE, PELICAN 1560-000-110-BLACK CASE, W/ SPECIAL MOBRIK-FOAM #BW1560
(HOLDS THE WELDER & PRESETTER)
1211172
CASE, PELICAN 1620-020-110-BLACK CASE, W/ SPECIAL MOBRIK-FOAM #BW1620
(HOLDS THE PUNCHER)
TGW NITTA BELT FULL WELD & PUNCH KITS
(RENTAL KITS ONLY!)
TGW Rental Kit Include: Finger Punch Press, T-wrench, Heated Weld Press, Pre-setter Mold,
Silicone Sheet, Instruction Manuals, and Flash Drive with Instruction Video. Each Press Kit Is
Shipped in a Hard Case.
NITTA BELT WELDER AND PUNCH HARD CASE
WITH SPECIAL MOBRIK FOAM
WARNING:
• Use Only TGW Nitta belt welder and punch equipment for TGW Nitta belt
splice/welding. Non-TGW Nitta belt welding or punch equipment is not
compatible with the TGW Nitta belt!
CAUTION
Top side of blue urethane belt after weld
Bottom side of blue urethane belt after weld
