NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 73 of 129
1.37: TERMINAL BLOCK DESCRIPTIONS
Table 5: Terminal Block Descriptions
Terminal Descriptions
TB1 Single release, Logic interrupt Pulse release.
This terminal is an isolated input; it must be used when signal voltage is from a
supply that is different than the supply powering CRUZcontrol logic assemblies.
It can be used when signal voltage is from same power supply that is powering
CRUZcontrol logic assemblies.
TB2 Slug release.
This terminal is an isolated input; it must be used when signal voltage is from a
supply that is different than the supply powering CRUZcontrol logic assemblies.
It can be used when signal voltage is from same power supply that is powering
CRUZcontrol logic assemblies.
TB3 Zone Status (TB3 only available on full function module)
This terminal is an isolated output; it must be used when signal voltage is from a
supply that is different than the supply powering CRUZcontrol logic assemblies.
It can be used when signal voltage is from same power supply that is powering
CRUZcontrol logic assemblies.
TB4 Inputs
This terminal is a non-isolated input; it must be used when signal voltage is from
same power supply that is powering CRUZcontrol logic assemblies.
TB5 Outputs
This terminal is a non-isolated outputs; output signal voltage is from same power
supply that is powering CRUZcontrol logic assemblies.
