NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 72 of 129
Slug Interrupt Downstream
Definition Downstream slug line is disconnected. Logic Assemblies downstream will not
slug release when the Slug Release signal goes high.
Configuration JP1, 2-3 all other jumper terminals should be on pins 1-2.
User Action No action required.
Slug Interrupt Upstream
Definition Upstream slug line is disconnected. Logic Assemblies upstream will not slug
release when the Slug Release signal goes high.
Configuration JP2, 2-3 all other jumper terminals should be on pins 1-2.
User Action No action required.
Zone Status Indication *
Definition Indicates full or empty status of the downstream zone on TB3.
Configuration JP4, 1-2 and JP5, 1-2 for logic status or 2-3 for sensor status, all other jumper
terminals should be on pins 1-2.
User Action Connect to TB3 for zone status.
The output transition of the Zone Status from OFF to ON or ON to OFF can be
delayed by the Zone Status ON and Zone Status OFF Delay potentiometers.
This is typically used to indicate a zone is full only after a product is detected for
period of time.
* On power up there will be a 24s delay on zone status. If the state changes
during that period, the delay will be eliminated.
