NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 83 of 129
1.43: ACCESSORIES
Auxiliary Photoelectric Sensor
There is often a need to sense product presence on a CRUZcontrol equipped conveyor, with the
sensors connected to a control system other than CRUZcontrol. To allow for this, adequate space has
been provided alongside of the CRUZcontrol photoelectric sensors to allow for the mounting of a
second independent photoelectric sensor, sharing the same holes through the conveyor side
channels and the same reflector. Appropriate holes are provided for the photoelectric sensor
mounting bracket. The discharge end of NBC conveyor is also provided with an additional mounting
location for a photoelectric sensor and reflector.
The following kits are available, which include the photoelectric sensor and appropriate bracket. Even
though not normally needed, an extra reflector and adhesive mounting tape is also included with each
kit.
The 10-30 VDC photo sensors are similar to the CRUZcontrol sensors. They are light operate, with a
50 mA maximum output current, and come with a 27" cable (no connector).
Part Number Description
1117727 PE, ASY SICK ZL PNP LIGHT OP 700MM LEAD W/ FLYING LEADS
W/REFLECTOR & TAPE
Table 10: Photoelectric sensor
Reflector
Replacement reflectors can be ordered with the following part number.
Part Number Description
400004 PE, REFLECTOR 4-3/8" X 1-1/8"
1153640 TAPE, FOAM DBL SIDED 3/4"SQUARE
Table 11: Reflector
Sensor Valve Assemblies
A Sensor Valve Assembly is used for applications not requiring accumulation logic, (controlling the
zone with a PLC) but the solenoid valve and photoelectric sensor configuration as used in the
CRUZcontrol channel is still desired.
Part Number Description
1116736 LM, CRUZCONTROL SENSOR/VALVE W/ZL2 EYE,N.O. VALVE
Table 12: Sensor Valve Assembly
