NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 65 of 129
A signal to release or accumulate product
This is normally a 24V signal from the system PLC to the release function module of the NBC. These
Function Modules will accept 115 VAC control inputs. There are some cautions that must be observed
to avoid Function Module hardware failure. Part numbers and complete wiring descriptions for release
function modules are explained in the NBC® Installation, Operation and Maintenance Manual – item
number 1118140.
Exercise extreme caution in activating the slug release line instead of the logic line. If used at all, it
should be limited to the discharge 20’ or less of conveyor. A slug interrupt cable (item number
1117382) can be used to break this signal where you want the slug release to stop. It should be noted
that the same result can be accomplished by switching the discharge logic modules from progressive
to basic.
