NBC™ Flat Belt - IOM
P/N: 1118140 Rev: 07/29/2020 Page 69 of 129
Logic Assembly Types
The CRUZcontrol Logic Assembly 1114947 provides an “air to brake” logic output utilizing a normally
open pneumatic valve. The pneumatic valve is energized for a zone to be running.
Logic Assembly Functions
The CRUZcontrol Logic Assembly comes with a momentary button on the front of the housing
allowing for selection of either Basic Logic or Progressive Logic mode. A Mode LED indicates either
Basic (green) or Progressive (amber) has been selected. Pressing and then releasing the button
toggles between the two modes.
Table 1: Logic Assemblies Functions
Function Basic Logic
Progressive
Logic
Single Accumulate Yes No
Slug Accumulate No Yes
Single Release Yes No
Slug Release Yes Yes
Logic Assembly Part Numbers
Table 2: Logic Assemblies Part Numbers
Part Number Description Used with
1114947 Basic/Progressive Logic Module, Air
to Brake,
NBC straight conveyor
