Thermal Dynamics MERLIN 6000 User Manual

APPENDIX 58 Manual 0-2568
APPENDIX V: QUICK REFERENCE TO INTERCONNECTING
CABLES AND HOSES
Cable/Hose Diameter
Cable Description Catalog # Inches mm
A Power Supply CNC Cable
25 ft (7.6 m) 8-3380 3/8 9.5
50 ft (15.2 m) 8-3381 3/8 9.5
75 ft (22.9 m) 8-3382 3/8 9.5
100 ft (30.5 m) 8-3383 3/8 9.5
B Remote Control Cable
25 ft (7.6 m) 9-5961 1/2 13
50 ft (15.2 m) 9-5962 1/2 13
75 ft (22.9 m) 9-5963 1/2 13
100 ft (30.5 m) 9-5964 1/2 13
C Remote Gas Select Cable
25 ft (7.6 m) 9-4579 1/2 13
50 ft (15.2 m) 9-4580 1/2 13
75 ft (22.9 m) 9-4581 1/2 13
100 ft (30.5 m) 9-4582 1/2 13
D Arc Starter Control Cable
35 ft (10.7 m) 9-6901 1/4 6
50 ft (15.2 m) 9-6902 1/4 6
75 ft (22.9 m) 9-6903 1/4 6
100 ft (30.5 m) 9-6904 1/4 6
125 ft (38.1 m) 9-6905 1/4 6
E Positive Pilot Supply Cable
35 ft (10.7 m) 9-6906 1/4 6
50 ft (15.2 m) 9-6907 1/4 6
75 ft (22.9 m) 9-6908 1/4 6
100 ft (30.5 m) 9-6886 1/4 6
115 ft (35.1 m) 9-6857 1/4 6
125 ft (38.1 m) 9-6909 1/4 6
F Plasma or Secondary Gas Hose #4
10 ft (3.0 m) 9-6910 1/2 13
15 ft (4.6 m) 9-6911 1/2 13
20 ft (6.1 m) 9-6912 1/2 13
25 ft (7.6 m) 9-6913 1/2 13
30 ft (9.1 m) 9-6914 1/2 13
35 ft (10.7 m) 9-6915 1/2 13
40 ft (12.2 m) 9-6916 1/2 13
50 ft (15.2 m) 9-6917 1/2 13
75 ft (22.9 m) 9-6918 1/2 13
100 ft (30.5 m) 9-6919 1/2 13
125 ft (38.1 m) 9-6920 1/2 13
G Coolant Hose #8
35 ft (10.7 m) 9-6921 7/8 22
50 ft (15.2 m) 9-6922 7/8 22
75 ft (22.9 m) 9-6923 7/8 22
100 ft (30.5 m) 9-6924 7/8 22
115 ft (35.1 m) 9-6858 7/8 22
125 ft (38.1 m) 9-6925 7/8 22
H Torch (-) Cable
25 ft (7.6 m) 9-6892 3/4 19
35 ft (10.7 m) 9-6926 3/4 19
50 ft (15.2 m) 9-6927 3/4 19
75 ft (22.9 m) 9-6928 3/4 19
100 ft (30.5 m) 9-6896 3/4 19
115 ft (35.1 m) 9-6856 3/4 19
125 ft (38.1 m) 9-6929 3/4 19
I Work Cable
25 ft (7.6 m) 9-6892 3/4 19
35 ft (10.7 m) 9-6926 3/4 19
50 ft (15.2 m) 9-6927 3/4 19
75 ft (22.9 m) 9-6928 3/4 19
100 ft (30.5 m) 9-6896 3/4 19
115 ft (35.1 m) 9-6856 3/4 19
125 ft (38.1 m) 9-6929 3/4 19
J Parallel Cable
8ft (2.4 m) 9-6800 1/2 13
K CNC Cable
5 ft (1.5 m) 9-4483 5/8 16
10 ft (3.0 m) 9-4484 5/8 16
15 ft (4.6 m) 9-4485 5/8 16
20 ft (6.1 m) 9-4486 5/8 16
25 ft (7.6 m) 9-4486-25 5/8 16
30 ft (9.1 m) 9-4486-30 5/8 16
50 ft (15.2 m) 9-4486-50 5/8 16
