APPENDIX 64 Manual 0-2568
APPENDIX XI: PARALLEL CABLE
Master Power
Supply J54
Slave Power
Supply J15
Cable
1
2
7
11
3
4
14
12
8
9
10
5
13
1
2
32
33
24
25
17
15
3
4
31
30
19
35
36
26
27
DEMAND
3.3 - 10 VDC
ENABLE
START/STOP
SLAVE IS ON
SLAVE OUTPUT
Signal
This Is Slave
Remote Installed
Shield Drain
A-01516
Isolation PC
Board Power
Supply
0 - 10 VDC
