Thermo Scientific 310 - Keypad Operation

Model 310 Series DH Incubator 1-3Thermo Scientific
Section 1
Installation and Start-up
The Model 310 Series direct heat incubator has four basic modes which
allow incubator setup: Run, Setpoints, Calibration and System
Configuration.
Run is the default mode which the incubator will normally be in during
operation.
Set is used to enter system setpoints for incubator operation.
Calibration is used to calibrate various system parameters.
Configuration allows for custom setup of various options.
The chart below shows the selections under each of the modes.
1
T/C units only Base Unit Displays
2
IR units only Option Displays
*T/C units only
Scroll for Parameters Arrows: Steps the operator through the parameters
of SET, CAL and CONFIG Modes. The right arrow goes to the next
parameter, the left arrow returns to the previous parameter.
Up Arrow: Increases or toggles the parameter value that has been selected
in the SET, CAL, and CONFIG Modes.
Enter: Must press Enter key to save to memory all changed values.
Down Arrow: Decreases or toggles the parameter values that have been
selected in the SET, CAL and CONFIG Modes.
Silence Key: Press to silence the audible alarm. See Section 4 for alarm
ringback times.
Keypad Operation
RUN SETPOINT CALIBRATION CONFIGURATION
Default Mode Temperature Temp Offset Audible
Overtemp CO2 Cal
1
Access Code
CO2 IR Cal
2
Temp Lo Alarm
RH Cal Temp Relay
CO2 Lo Alarm
CO2 Hi Alarm
CO2 Relay
CO2 Z & S #'s *
RH Lo Alarm
RH Relay
Display Temp
Display Rh
Tank Select
Gas Guard
RS485 Address
