Section 6 Factory Options
Descriptions for connections to external equipment follow.
A set of relay contacts is provided to monitor alarms through an RJ11
telephone style connector on the back of the cabinet. Refer to Figure 6-3
for the location of the alarm connector. The 12-foot telephone cord (P/N
190388) and RJ11-to-screw terminal conversion box (190392) are
available through our service department.
The remote alarm provides a NO (normally open) output, an NC
(normally closed) output and COM (common). Refer to Figure 6-1.
The contacts will trip on a power outage or an overtemperature condition.
The contacts may also be programmed to trip or not trip on temperature
alarms, CO
2 alarms, and RH alarms. See Section 3, Configuration Mode.
Figure 6-1. Remote Alarm Output
Model 310 Series DH Incubator 6-1Thermo Scientific
Connect Remote
Alarm Contacts
