Order of mounting a rear camera _ SUV
②
③
Remove the top of
the trunk weather
strip.
※ The tasks up to C
pillar are same as
for a car.
Remove the trunk
door trim.
Remove the fixing
hook from the
indoor ceiling.
Ensure the cable
penetrating C
pillar passes
through the indoor
material(Ceiling)
and reaches the
tube in the top.
28
①
④
