MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 21 THOMSON TECHNOLOGY
Iveco (J1939)
Warnings and shutdowns
J1939 codes
Warning/shutdown list
SPN
FMI
warning
FMI
shutdown
Low oil pressure 100 17 1
Intake manifold #1 P 102 15 -
Coolant temperature 110 15 0
High inlet air temp. 172 15 -
Fuel temperature 174 15 -
Overspeed 190 15 0
EIC yellow lamp - X -
EIC red lamp - - X
Write commands to engine controller
•
Engine controls
All the write commands to the engine controller (ex: speed, start/stop, etc.) are enabled in
setting 7563 (EIC Controls).
•
Engine speed
CANbus ID for speed control: 0xc000003.
For J1939 TSC1, the source address of the ML-2 controller is 3.
For the Iveco Vector 8 type only: CANbus ID for speed control: 0xcFF0027.
The speed regulation is enabled in setting 2781 (Reg. output
) and 7563 (EIC
Controls).
FMI indication ‘ – ‘ means that the alarm in question is not supported.
