MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 30 THOMSON TECHNOLOGY
Volvo Penta EMS 2 (J1939)
EMS 2 and EDCIII/D6, D7, D9, D12 and D16 (GE and AUX variants only).
Warnings and shutdowns
J1939 codes
Warning/shutdown list
SPN
FMI
warning
FMI
shutdown
Low oil pressure 100 5 -
Intake manifold #1 P 102 - -
Coolant temperature 110 5 -
High inlet air temp. 172 5 -
Fuel temperature 174 - -
Fuel pressure 94 5 -
Oil level 98 5 -
Overspeed 190 - 0
Coolant level low 111 - 1
EIC yellow lamp - X -
EIC red lamp - - X
Write commands to engine controller
•
Engine controls
All the write commands to the engine controller (ex: speed, start/stop, etc.) are enabled in
setting 7563 (EIC Controls).
•
Engine speed
CANbus ID for speed control: 0x0cff4611 – Volvo Penta proprietary telegram.
•
Preheat
•
Start/stop
Readable states
•
Preheat and running
The speed regulation is enabled in setting 2781 (Reg. output) and 7563 (EIC
Controls).
Selection of primary or secondary speed is selected in setting 2774.
FMI indication “ – “ means that the alarm in question is not supported,
