MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 39 THOMSON TECHNOLOGY
Alarms, MTU ADEC
Alarm, status and measurement table (read only) function code 04h.
Addr. Content Type
1020 EIC alarms, MEC 310
controller
Bit 0 EIC communication error
Bit 2 EIC shutdown
Bit 3 EIC overspeed
Bit 4 EIC coolant water temperature 1
Bit 5 EIC coolant water temperature 2
Bit 6 EIC oil pressure 1
Bit 7 EIC oil pressure 2
1022 EIC alarms, engine
controller
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
ECU power supp voltage LoLo
Fuel high temp
Exhaust A high temp
Exhaust B high temp
Pressure 1 high (Aux 1)
Pressure 2 high (Aux 2)
Day tank high level
Day tank low level
Run-up speed not reached
Idle speed not reached
1023 EIC alarms, engine
controller
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14
Bit 15
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
Common alarm red
Overspeed
Lube oil press LowLow
Coolant temperature HiHi
Lube oil temp HiHi
Charge air temp HiHi
ECU power supp voltage HiHi
Generator temp high warning
Holding tank high level
Holding tank low level
Winding 1 temp high
Winding 2 temp high
Winding 3 temp high
Ambient temp high
Water in fuel 1
Water in fuel 2
1024 EIC alarms, engine
controller
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10
Bit 11
Bit 12
Bit 13
Bit 14
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
EIC
Coolant high temp
Charge air high temp
Intercooler coolant high temp
Lube oil high temp
ECU high temp
Engine speed low
Prelube fail
Start speed not reached Common alarm
yellow
Lube oil pressure low
Coolant level low
Intercooler coolant level low
ECU defect
Speed demand defect
Power supply low voltage
