MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 38 THOMSON TECHNOLOGY
Alarms, Iveco
Alarm, status and measurement table (read only) function code 04h.
Addr. Content Type
1020 EIC alarms, MEC 310
controller
Bit 0 7570 EIC communication error
Bit 1 7580 EIC warning
Bit 2 7590 EIC shutdown
Bit 3 7600 EIC overspeed
Bit 4 7610 EIC coolant water temperature 1
Bit 5 7620 EIC coolant water temperature 2
Bit 6 7630 EIC oil pressure 1
Bit 7 7640 EIC oil pressure 2
1024 EIC alarms, engine
controller (DM 1)
Bit 1 EIC low oil pressure, warning
Bit 2 EIC low oil pressure, shutdown
Bit 3 EIC boost pressure, warning
Bit 4 EIC high coolant temperature, warning
Bit 5 EIC high coolant temperature, shutdown
Bit 6 EIC high inlet air temperature, warning
Bit 7 EIC fuel temperature, warning
Bit 8 EIC ECM yellow lamp, warning
Bit 9 EIC ECM red lamp, shutdown
Bit 10 EIC overspeed, warning
Bit 11 EIC overspeed, shutdown
Alarms, JDEC – John Deere engines
Alarm, status and measurement table (read only) function code 04h.
Addr. Content Type
1020 EIC alarms, MEC 310
controller
Bit 0 7570 EIC communication error
Bit 1 7580 EIC warning
Bit 2 7590 EIC shutdown
Bit 3 7600 EIC overspeed
Bit 4 7610 EIC coolant water temperature 1
Bit 5 7620 EIC coolant water temperature 2
Bit 6 7630 EIC oil pressure 1
Bit 7 7640 EIC oil pressure 2
1024 EIC alarms, engine
controller (DM 1)
Bit 0 EIC high coolant temperature, shutdown
Bit 1 EIC low oil pressure, shutdown
Bit 2 EIC fuel temperature, shutdown
Bit 3 EIC fuel control valve, shutdown
Bit 4 EIC ECU failure, shutdown
Bit 5 EIC oil pressure, warning
Bit 6 EIC intake manifold, warning
Bit 7 EIC coolant temperature, warning
Bit 8 EIC fuel injection pump, warning
Bit 9 EIC JDEC shutdown (LS: lamp status)
Bit 10 EIC JDEC warning (LS: lamp status)
