MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 29 THOMSON TECHNOLOGY
•
Frequency selection
Nominal speed/frequency is selected in 2772. If ‘User’ is selected, nominal
speed/frequency is written automatically, based on the frequency nominal setting.
•
Start/stop command
Control
In the parameter 2770 it is possible to configure the droop setting and the initial speed setting.
Volvo Penta EMS (J1939)
Warnings and shutdowns
J1939 codes
Warning/shutdown list
SPN
FMI
warning
FMI
shutdown
Low oil pressure 100 5 -
Intake manifold #1 P 102 - -
Coolant temperature 110 5 -
High inlet air temp. 172 5 -
Fuel temperature 174 - -
Fuel pressure 94 5 -
Oil level 98 5 -
Overspeed 190 - 0
Coolant level low 111 - 1
EIC yellow lamp - X -
EIC red lamp - - X
Write commands to engine controller
None.
The speed regulation is enabled in setting 2781 (Reg. output) and 7563 (EIC
Controls).
It is only possible to write commands to the engine when the Scania Coordinator
is NOT mounted.
