THOMSON MEC 310#GENSET CONTROLLER OPTION J-CANBUS J1939 User Manual

MEC 310 GENSET CONTROLLER -
Option J – CANbus J1939
PM077 R1 09/08/20 Page 28 THOMSON TECHNOLOGY
Flash code MEC310 displayed text Description
11 Overreving One or both engine speed sensors have indicated above
3000 RPM
12 Speed sensor 1 Engine sensor 1
13 Speed sensor 2 Engine sensor 2
14 Water T sen. Engine coolant temperature sensor
15 Char. air T sen Charge air temperature sensor
16 Char. air P sen Charge air pressure sensor
17 Oil temp. sen. Oil temperature sensor
18 Oil pres. sen. Oil pressure sensor
23 Fault in cor. Fault in coordinator
25 Throttle pedal CAN message for fine tune nominal speed out of range
27 Emerg. stop o.r Engine stop overridden
31 Oil pres. prot Oil pressure protection activated
32 Wrong parameter Wrong parameter setting for defect CAN communication
33 Battery voltage Battery voltage out of range
37 Emerg. stop cor Emergency stop switch activated
43 CAN cir. defect CAN circuit defect
48 CAN mess. DLN1 CAN message from the coordinator missing or not correct
49 Wrong CAN ver. Non-matching CAN version in EMS and coordinator
51 Un. inj. cyl. 1 Unit injector cylinder 1
52 Un. inj. cyl. 2 Unit injector cylinder 2
53 Un. inj. cyl. 3 Unit injector cylinder 3
54 Un. inj. cyl. 4 Unit injector cylinder 4
55 Un. inj. cyl. 5 Unit injector cylinder 5
56 Un. inj. cyl. 6 Unit injector cylinder 6
57 Un. inj. cyl. 7 Unit injector cylinder 7
58 Un. inj. cyl. 8 Unit injector cylinder 8
59 Extra ana. inp. Voltage out of range on extra analogue input pin
61 System shutdown System shut down incorrectly
66 Coola. l. prot. Low engine coolant level
86 HW watchdog Hardware watchdog
87 Fault in RAM The EMS has detected that the fault code memory is not
functioning correctly
89 Seal The program in the EMS has been altered in a prohibited
manner
94 Coola. shut off Engine coolant temperature/oil pressure shutdown
96 Overheat prot. Overheat protection activated
99 Fault in TPU Error in TPU Timer Processor Unit
Write commands to engine controller
•
Engine controls
All the write commands to the engine controller (ex: speed, start/stop, etc.) are enabled in
setting 7563 (EIC Controls)
•
Droop
•
Engine speed
CANbus ID: Offset: 0xcfff727
Speed: 0x0cff8027
