Alarms, Scania
Alarm, status and measurement table (read only) function code 04h.
Addr. Content Type
1026 EIC alarms (KWP 2000) Bit 0 EIC overreving
Bit 1 EIC speed sensor 1
Bit 2 EIC speed sensor 2
Bit 3 EIC water temp. sensor
Bit 4 EIC charge air temp. sensor
Bit 5 EIC charge air pressure sensor
Bit 6 EIC oil temp. sensor
Bit 7 EIC oil pressure sensor
Bit 8 EIC fault in cor.
Bit 9 EIC throttle pedal
Bit 10 EIC emergency stop override
Bit 11 EIC oil pressure prot.
Bit 12 EIC wrong parameter
Bit 13 EIC battery voltage
Bit 14 EIC oil pressure prot.
Bit 15 EIC emergency stop cor.
1027 EIC alarms (KWP 2000) Bit 0 EIC CAN cir. defect
Bit 1 EIC CAN mess. DLN1
Bit 2 EIC Wrong CAN version
Bit 3 EIC un. inj. cyl. 1
Bit 4 EIC un. inj. cyl. 2
Bit 5 EIC un. inj. cyl. 3
Bit 6 EIC un. inj. cyl. 4
Bit 7 EIC un. inj. cyl. 5
Bit 8 EIC un. inj. cyl. 6
Bit 9 EIC un. inj. cyl. 7
Bit 10 EIC un. inj. cyl. 8
Bit 11 EIC extra ana. inp.
Bit 12 EIC system shutdown
Bit 13 EIC coola. L. prot.
Bit 14 EIC HW watchdog
Bit 15 EIC fault in RAM
1028 EIC alarms (KWP 2000) Bit 0 EIC seal
Bit 1 EIC coola. shut OFF
Bit 2 EIC overheat prot.
Bit 3 Fault in TPU
Bit 4 Not used
Bit 5 Not used
Bit 6 Not used
Bit 7 Not used
Bit 8 Not used
Bit 9 Not used
Bit 10 Not used
Bit 11 Not used
Bit 12 Not used
Bit 13 Not used
Bit 14 Not used
Bit 15 Not used
