© 2016 Thorlabs Scientific Imaging496
DCx Camera Functional Description and SDK Manual
Parameter
Description
Value range
Example
Bayer Conversion
Sets the size of the Bayer
conversion mask for the
current color format when
using color cameras
1, 2
*2
1
[Auto features]
Sets the parameters for automatic image control
Auto Framerate control
Enable frame rate control
0, 1
0
Brightness exposure
control
Enable exposure time
control
0, 1
0
Brightness gain control
Enable sensor gain control
0, 1
0
Auto Framerate Sensor
control
Enable the senor-internal
control for frame rates (see
also
is_SetAutoParameter())
0 = off
1 = on
0
Brightness exposure
Sensor control
Enable the sensor-internal
brightness control
0 = off
1 = on
0
Brightness gain Sensor
control
Enable the sensor-internal
gain control
0 = off
1 = on
0
Brightness exposure
Sensor control
photometry
Not supported by DCx
cameras
Brightness gain Sensor
control photometry
Not supported by DCx
cameras
Brightness control once
0, 1
0
Brightness reference
Reference value for
brightness control
0...255
128
Brightness speed
Brightness control speed
0...100
50
Brightness max gain
Maximum gain for
brightness control
0...100
100
Brightness max exposure
Maximum exposure time
for brightness control
Depends on Pixelclock
and image geometry
66.082816
Brightness Aoi Left
X start point of reference
AOI for brightness control
0...(max. width
*1
-Aoi
Width)
0
Brightness Aoi Top
Y start point of reference
AOI for brightness control
0...(max. height
*1
-Aoi
Height)
0
Brightness Aoi Width
Width of reference AOI for
brightness control
Sensor-dependent
*1
2560
Brightness Aoi Height
Height of reference AOI for
brightness control
Sensor-dependent
*1
1920
Brightness Hysteresis
Hysteresis value for auto
exposure and gain (see
IS_SET_AUTO_HYSTERESIS)
0…10
2
Brightness Skip Frames
Number of images that will
be not analyzed for the
control (see
IS_SET_AUTO_SKIPFRAMES)
0…1000
4
