6 Appendix
497
Parameter
Description
Value range
Example
Auto WB control
Enable white balance
control
0, 1
0
Auto WB type
White balance mode
Auto WB RGB color mode
Color space of white
balance (only active, if the
mode "Auto (Kelvin)" is
set)
Auto WB offsetR
Red offset for white
balance control
0...100
0
Auto WB offsetB
Blue offset for white
balance control
0...100
0
Auto WB gainMin
Minimum gain for white
balance control
0 <= gainMin <= gainMax
<= 100
0
Auto WB gainMax
Maximum gain for white
balance control
0 <= gainMin <= gainMax
<= 100
100
Auto WB speed
White balance control
speed
0...100
50
Auto WB Aoi Left
X start point of reference
AOI for white balance
control
0...(max. width
*1
-Aoi
Width)
0
Auto WB Aoi Top
Y start point of reference
AOI for white balance
control
0...(max. height
*1
-Aoi
Height)
0
Auto WB Aoi Width
Width of reference AOI for
white balance control
Sensor-dependent
*1
2560
Auto WB Aoi Height
Height of reference AOI for
white balance control
Sensor-dependent
*1
1920
Auto WB Once
Carry out white balance
control once
0, 1
0
Auto WB Hysteresis
Hysteresis value for auto
white balance (see
IS_SET_AUTO_WB_HYSTERES
IS)
0…10
2
Auto WB Skip Frames
Number of images that will
not be analyzed for control
(see
IS_SET_AUTO_WB_SKIPFRAM
ES)
0…1000
4
[Trigger and Flash]
Sets the digital inputs/outputs
Trigger mode
Trigger mode
Trigger timeout
Timeout value for triggered
image capture in 10 ms
steps
Trigger delay
Delay of triggered image
capture in µs
Sensor-dependent
*1
15
Trigger debounce mode
Not supported by DCx
