© 2016 Thorlabs Scientific Imaging498
DCx Camera Functional Description and SDK Manual
Parameter
Description
Value range
Example
cameras
Trigger debounce delay
time
Not supported by DCx
cameras
10
Trigger burst size
Not supported by DCx
cameras
Flash strobe
Activate flash output
0...6
*2
0
Flash delay
Delay of the flash signal in
µs
Depends on sensor
setting, can be queried
using is_IO()
0
Flash duration
Duration of the flash signal
in µs
Depends on sensor
setting, can be queried
using is_IO()
200
PWM mode
PWM mode
see is_IO()
PWM frequency
Frequency of the pulse-
width modulation
PWM duytcycle
Duty cycle of the pulse-
width modulation
0.0…1.0 (1.0 corresponds
to 100 %)
GPIO state
State of the GPIO
see is_IO()
GPIO direction
Direction of the GPIO
see is_IO()
[Sequence AOI]
The sequence AOI is supported by DCC1240x / DCC3240x models
only.
NumberUsedAOI
Number of used AOIs
see is_AOI()
StartX1…StartX3
X position of AOI 1-3
StartY1…StartY3
Y position of AOI 1-3
Gain1…Gain3
Gain of AOI 1-3
Exposure1…Exposure3
Exposure of AOI 1-3
ReadoutCycle1…
ReadoutCycle3
Number of read-out cycles
of AOI 1-3
BinningMode1…
BinningMode3
Binning mode of AOI 1-3
SubsamplingMode1…
SubsamplingMode3
Subsampling mode of AOI
1-3
ScalerFactor1…
ScalerFactor3
Scaling factor of AOI 1-3
DetachImageParameter1…
DetachImageParameter3
Changes of exposure time
and gain are transferred to
AOI 1-3
0 = Every change is
transferred
1 = Changes are not
transferred
see also is_AOI()
[Transfer]
Not supported by DCx cameras
ImageDelay_us
PacketInterval_us
*
1
This information is provided in Camera and sensor data chapter.
*
2
For the parameters, please refer to the uc480.h header file provided in the \Develop\include
