THORLABS DCU223 SERIES Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging
4 Programming (SDK)
113
4.2.6 Using Inputs and Outputs
Depending on the model, DCx Cameras have one or more digital inputs and outputs designed for
different purposes.
Input/output control: Here, you will find functions for setting the DCxCamera's I/Os and for using
the trigger and flash modes.
4.2.6.1 Input/Output Control
With these functions you can use the camera's digital in-/outputs for trigger and flash control.
is_SetExternalTrigger()
Enables the digital input for trigger operation or returns the
applied signal level.
is_IO()
Sets the digital output for flash control or a static output
level.
is_IO()
Sets the delay and power-on time of the flash output.
is_SetTriggerDelay()
Sets the trigger signal delay time.
is_IO()
Determines the delay and power-on times of the flash
output to obtain a global shutter effect when using rolling
shutter sensors.
is_ForceTrigger()
Simulates a trigger signal in hardware trigger mode.
With these commands you can activate additional functions or use GPIOs on some DCx Cameras.
is_IO()
Sets the additional digital outputs (GPIO).
is_IO()
Defines each port as a digital input or output (GPIO).
is_IO()
Toggles the color of the status LED for DCU22x and
DCC1240x cameras.
