THORLABS DCU223 SERIES Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging
4 Programming (SDK)
339
4.3.80 is_SetColorCorrection
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_SetColorCorrection (HIDS hCam, INT nEnable, double* factors)
Description
For color cameras, is_SetColorCorrection() enables color correction in the uc480 driver. This
enhances the rendering of colors for cameras with color sensors. Color correction is a digital
correction based on a color matrix which is adjusted individually for each sensor.
Note
After changing this parameter, perform manual or automatic white balancing in order to obtain
correct color rendering (see also is_SetAutoParameter()).
Input parameters
hCam
Camera handle
nEnable
IS_CCOR_ENABLE_NORMAL
Enables simple color correction. This parameter
replaces IS_CCOR_ENABLE.
IS_CCOR_ENABLE_BG40_ENHANCED
Enables color correction for cameras with
optical IR filter glasses of the BG40 type.
IS_CCOR_ENABLE_HQ_ENHANCED
Enables color correction for cameras with
optical IR filter glasses of the HQ type.
IS_CCOR_SET_IR_AUTOMATIC
Enables color correction for cameras with
optical IR filter glasses. The glass type is set
automatically as specified in the camera
EEPROM.
IS_CCOR_DISABLE
Disables color correction.
IS_GET_CCOR_MODE
Returns the current setting.
IS_GET_SUPPORTED_CCOR_MODE
Returns all supported color correction modes.
See the Return values section.
IS_GET_DEFAULT_CCOR_MODE
Returns the default color correction mode.
factors
Sets the strength of the color correction between
0.0 (no correction) and 1.0 (strong correction).
Return values
When used together with
IS_GET_CCOR_MODE
Current setting
When used together with
IS_GET_SUPPORTED_CCOR_MODE
When used for color cameras and together with
IS_GET_SUPPORTED_CCOR_MODE, this parameter
returns the supported values linked by a logical
OR:
IS_CCOR_ENABLE_NORMAL
IS_CCOR_ENABLE_BG40_ENHANCED
