DCx Camera Functional Description and SDK Manual
4.3.37 is_GetCameraLUT
USB 3.0
USB 3.0
Syntax
INT is_GetCameraLUT (HIDS hCam,
UINT Mode, UINT NumberOfEntries,
double* pRed_Grey,
double* pGreen,
double* pBlue)
Description
is_GetCameraLUT() returns the current LUT values. Using the is_SetCameraLUT() function, you can
select a different LUT for the camera.
Note
The is_SetCameraLUT() function is only supported by DCC3240 cameras.
Input parameters
hCam
Camera handle
Mode
IS_GET_CAMERA_LUT_USER
Returns the LUT values set by the user without
modifications.
IS_GET_CAMERA_LUT_COMPLETE
Returns the LUT values set by the user after the gamma,
contrast and brightness values have been taken into
account.
NumberOfEntries
Number of the LUT values
IS_CAMERA_LUT_64
LUT with 64 values
pRed_Grey
Pointer to the array to which the red channel
values or the gray scale value of the LUT are
written.
pGreen
Pointer to the array to which the green channel
values of the LUT are written.
pBlue
Pointer to the array to which the blue channel
values of the LUT are written.
Return values
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_NO_SUCCESS
General error message
IS_NOT_SUPPORTED
The camera model used here does not support this
function or setting.
IS_SUCCESS
Function executed successfully
