DCx Camera Functional Description and SDK Manual
Subsampling
Mode
Horizontal + vertical
Method
Monochrome/color:
automatic
Factor
2x, 3x, 4x, 5x, 6x, 8x, 16x
Hardware trigger
Mode
Asynchronous
Trigger delay with rising
edge
µs
3 ±0.25
*6
Trigger delay with falling
edge
µs
21 ±0.25
*6
Adjustable trigger delay
µs
15 – 4 000 000
Power consumption
*5
USB 3 uc480 CP Rev. 2
W
1.4 – 2.4
** Not yet defined.
*1 The maximum possible pixel clock frequency depends on the PC hardware used.
*2 Requires maximum pixel clock frequency.
*3 Requires minimum pixel clock frequency.
*4 Use of this function increases the frame rate.
*5 The power consumption depends on the sensor model and the pixel clock setting.
*6 Not yet confirmed
Please see also the DCC3260 application notes chapter.
Relative sensor sensitivity
The cut-off wavelength of the IR cut filter is at 650 nm (if the IR cut filter is used in the camera
model).
5.3.2 DCC1240x / DCC3240x
Sensor specification
Sensor type
CMOS
Shutter system
Electronic global and rolling shutter
Characteristic
Linear
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.3 Megapixel)
Aspect ratio
5:4
Bit depth
10 bits *
8
Optical sensor class
1/1.8 inch
