© 2016 Thorlabs Scientific Imaging120
DCx Camera Functional Description and SDK Manual
4.3.3 is_AOI
Syntax
INT is_AOI (HIDS hCam, UINT nCommand, void* pParam, UINT nSizeOfParam)
Description
is_AOI() can be used to set the size and position of an area of interest (AOI) within an image. The
following AOIs can be defined:
Image AOI – display of an image portion
Auto Brightness AOI – reference area of interest for automatic brightness control
Auto Whitebalance AOI – reference area of interest for automatic white balance control
The nCommand input parameter is used to select the function mode. The pParam input parameter
depends on the selected function mode. If you select functions for setting or returning a value,
pParam contains a pointer to a variable of the UINT type. The size of the memory area to which
pParam refers is specified in the nSizeOfParam input parameter.
Note
Previous AOI functions
The is_AOI() function comprises all the functions for setting and positioning an AOI. The following
uc480 API commands are therefore obsolete:
is_SetAOI()
is_SetImageAOI()
is_SetImageSize()
is_SetImagePos()
See also Obsolete functions
AOI for automatic image control
The AOI for automatic brightness control (AES/AGC) and automatic white balance (AWB) defaults
to the same size as the current image (i.e. the image AOI).
After changes to the image geometry (by resetting an image AOI, by binning or subsampling), the
AOIs for automatic image control will always be reset to the image AOI value. This means that it
might be necessary to set the AOIs for auto brightness/auto white balance again manually.
Fast changes of AOI position
Using the IS_AOI_IMAGE_SET_POS_FAST command, you can change the positions of AOIs very
quickly. Executing this command takes just a few milliseconds. When using this command, a few
special requirements have to be met:
The command is currently not supported by all DCx Cameras. With the
IS_AOI_IMAGE_SET_POS_FAST_SUPPORTED command, you can check whether your sensor supports
fast position changes.
Hot pixel correction has to be disabled (see is_HotPixel()).
Image capture is not suspended for fast AOI position changes. As a result, when you call the
command, a number of images might still be transferred with the old AOI position if they were in
the driver buffer at that moment.
