THORLABS DCU223 SERIES Description And Sdk Manual

© 2016 Thorlabs Scientific Imaging
4 Programming (SDK)
253
4.3.52 is_GetSupportedTestImages
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_GetSupportedTestImages (HIDS hCam, INT* SupportedTestImages)
Description
is_GetSupportedTestImages() returns all test images supported by the camera. You can enable
the sensor test image feature using is_SetSensorTestImage().
Input parameters
hCam
Camera handle
SupportedTestImages
Returns a bit mask of all test images
supported by the camera.
IS_TEST_IMAGE_NONE
No test image
IS_TEST_IMAGE_WHITE
White image
IS_TEST_IMAGE_BLACK
Black image
IS_TEST_IMAGE_HORIZONTAL_GREYSCALE
Horizontal grayscale
IS_TEST_IMAGE_VERTICAL_GREYSCALE
Vertical grayscale
IS_TEST_IMAGE_DIAGONAL_GREYSCALE
Diagonal grayscale
IS_TEST_IMAGE_WEDGE_GRAY_SENSOR
Gray wedges, generated by the sensor
IS_TEST_IMAGE_WEDGE_COLOR
Color wedges
IS_TEST_IMAGE_ANIMATED_WEDGE_GRAY_SENSOR
Gray wedges, animated, generated by the
sensor
IS_TEST_IMAGE_ANIMATED_WEDGE_COLOR
Color wedges, animated
IS_TEST_IMAGE_COLOR_BARS1
Color bars
IS_TEST_IMAGE_GREY_AND_COLOR_BARS
Gray and color bars
IS_TEST_IMAGE_MOVING_GREY_AND_COLOR_BARS
Gray and color bars, animated
IS_TEST_IMAGE_ANIMATED_LINE
Line, animated
IS_TEST_IMAGE_ALTERNATE_PATTERN
Alternating pattern (raw Bayer mode only)
IS_TEST_IMAGE_RAMPING_PATTERN
Diagonal color pattern
IS_TEST_IMAGE_MONOCHROME_HORIZONTAL_BARS
Monochrome bars, horizontal
IS_TEST_IMAGE_MONOCHROME_VERTICAL_BARS
Monochrome bars, vertical
IS_TEST_IMAGE_COLDPIXEL_GRID
Camera image overlaid with a grid of blue
dots
IS_TEST_IMAGE_HOTPIXEL_GRID
Camera image overlaid with a grid of red
dots
IS_TEST_IMAGE_VARIABLE_GREY
Adjustable grayscale image
IS_TEST_IMAGE_VARIABLE_RED_PART
Image with adjustable red content
IS_TEST_IMAGE_VARIABLE_GREEN_PART
Image with adjustable green content
IS_TEST_IMAGE_VARIABLE_BLUE_PART
Image with adjustable blue content
