DCx Camera Functional Description and SDK Manual
5.3.5 DCU223x
Sensor specification
Sensor type
CCD
Shutter system
Electronic global shutter
Characteristic
Linear
Readout mode
Progressive scan
Resolution class
XGA
Resolution
1024 x 768 pixels (0.79 Megapixel)
Aspect ratio
4:3
Bit depth
12 bits
Optical sensor class
1/3 inch
Exact sensitive area
4.762 x 3.571 mm
Exact optical sensor diagonal
5.95 mm (1/2.69 inch)
Pixel size
4.65 µm, square
Sensor name, monochrome
Sony ICX204AL
Sensor name, color
Sony ICX204AK
Gain
Monochrome model (master
gain)
10.47x
Color model (master/RGB)
7.59x/4.0x
Analog gain boost
2.0x (monochrome model only)
Camera timing
Pixel clock range (allowed/
recommended)
MHz
5 to 30 / 10 to 20
*1
Pixel clock for optimal image
quality
MHz
15
*1
Max. pixel clock with
subsampling/binning
MHz
30
*1
Frame rate (freerun mode)
fps
30.0
*2
Frame rate (trigger mode, 1 ms
exposure)
fps
28.7
*2
Exposure time in freerun mode
ms
0.030
*2
to 773
*3
Exposure time in trigger mode
ms
0.030
*2
to 10 min
*3
AOI
Mode
Horizontal + Vertical
*4
AOI image width, step width
Pixels
16 to 1024, 4
Mono: AOI image height, step
width
Pixels
120 to 768, 1
Color: AOI image height, step
width
Pixels
120 to 768, 2
Mono: AOI position grid
horizontal, vertical
Pixels
1, 1
