Page #226 background imageLoading...
Page #226 background image
© 2013 Thorlabs GmbH224
DCx Cameras
IS_NO_SUCCESS
General error message
IS_NOT_CALIBRATED
The camera does not contain any calibration data.
IS_NOT_SUPPORTED
The camera model used here does not support this function or
setting.
IS_OUT_OF_MEMORY
No memory could be allocated.
IS_TIMED_OUT
A timeout occurred. An image capturing process could not be
terminated within the allowable period.
IS_SUCCESS
Function executed successfully
IS_TRANSFER_ERROR
Transfer error. Frequent transfer errors can mostly be avoided by
reducing the pixel rate.
Related functions
is_HasVideoStarted()
is_IsVideoFinish()
is_SetExternalTrigger()
is_ForceTrigger()
is_CaptureVideo()
is_SetTimeout()
is_CaptureStatus()
Example
Enable trigger mode, set high-active flash mode and capture an image:
is_SetExternalTrigger(hCam, IS_SET_TRIGGER_SOFTWARE);
// Set the flash to a high active pulse for each image in the trigger mode
UINT nMode = IO_FLASH_MODE_TRIGGER_HI_ACTIVE;
is_IO(m_hCam, IS_IO_CMD_FLASH_SET_MODE, (void*)&nMode, sizeof(nMode));
is_FreezeVideo(hCam, IS_WAIT);
Sample programs
SimpleAcquire (C++)
uc480C# Demo (C#)
