© 2013 Thorlabs GmbH188
DCx Cameras
4.3.12 is_Convert
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
IDSEXP is_Convert(HIDS hCam, UINT nCommand, void* pParam, UINT cbSizeOfParam)
Description
is_Convert() is a general function for conversions. In version 4.20 a raw Bayer image is converted to the
desired format. You can set all parameters, which are important for software conversion:
Pixel format
Pixel converter (3×3, 5×5)
Color correction
Gamma
Saturation
Edge enhancement
The target buffer must be allocated with the is_AllocImageMem() function and must have the right size.
The nCommand input parameter is used to select the function mode. The pParam input parameter depends on the
selected function mode. If you select functions for setting or returning a value, pParam contains a pointer to a
variable of the UINT type. The size of the memory area to which pParam refers is specified in the
cbSizeOfParam input parameter.
Note
The following functions are obsolete by the is_Convert() function:
is_ConvertImage()
is_SetConvertParam()
See also Obsolete functions
Input parameters
hCam
Camera handle
nCommand
IS_CONVERT_CMD_APPLY_PARAMS_AND_CONVERT_B
UFFER
Converts a raw Bayer buffer with the passed conversion
parameters
pParam
Pointer to a function parameter, whose function depends
on nCommand.
cbSizeOfParam
Size (in bytes) of the memory area to which pParam
refers.
