© 2013 Thorlabs GmbH356
DCx Cameras
4.3.102 is_WaitForNextImage
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_WaitForNextImage(HIDS hCam, UINT timeout, char** ppcMem, INT* imageID)
Description
is_WaitForNextImage() returns the pointer and sequence ID of the first (i.e. oldest) image in a memory
sequence. The queue mode has to be enabled for the memory sequence (see is_InitImageQueue() ). If the
sequence does not contain images, is_WaitForNextImage() waits until a new image arrives or until the
specified time has elapsed.
Note
Note that also image capture errors are added to the ImageQueue like images. If a call of
is_WaitForNextImage() returns the IS_CAPTURE_STATUS return value then you can check by a new call of
the function, if any further images were enqueued into the ImageQueue after the error.
Attention
Image memories in a sequence with queue mode are automatically locked. The image memories will have to be
unlocked with is_UnlockSeqBuf() in order to be re-used in the sequence.
Input parameters
hCam
Camera handle
timeout
Timeout in ms. Range 0…2
32
-1
If no images are in the sequence and no image arrives during the timeout, the
function returns IS_TIMED_OUT.
ppcMem
Pointer to a variable which will receive the address of the last image in the
sequence.
imageID
Pointer to a variable which will receive the sequence ID of the oldest image in
the sequence.
Return values
IS_CANT_COMMUNICATE_WITH_DRIVER
Communication with the driver failed because no driver
has been loaded.
IS_CANT_OPEN_DEVICE
An attempt to initialize or select the camera failed (no
camera connected or initialization error).
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_INVALID_MEMORY_POINTER
Invalid pointer or invalid memory ID
IS_INVALID_PARAMETER
One of the submitted parameters is outside the valid
range or is not supported for this sensor or is not
available in this mode.
IS_IO_REQUEST_FAILED
An IO request from the uc480 driver failed. Possibly the
versions of the uc480_api.dll (API) and the driver file
(uc480_usb.sys) do not match.
IS_NO_SUCCESS
General error message
IS_SUCCESS
Function executed successfully
IS_TIMED_OUT
A timeout occurred. An image capturing process could
not be terminated within the allowable period.
IS_CAPTURE_STATUS
A transfer error occurred or no image memory was
available for saving.
The parameter IS_CAPTURE_STATUS replaces the
previous parameter IS_TRANSFER_FAILED.
278
354
