© 2013 Thorlabs GmbH504
DCx Cameras
6.4 uc480 Parameter File (ini file)
Using the is_ParameterSet() function, you can save the currently set DCx camera parameters to a file in the ini
format (*.ini) or load an ini file.
Attention
Only camera-specific ini files can be loaded.
The ini file you want to load has to match the paired camera model.
When loading an ini file, make sure that the image size (AOI) and color depth parameters in the ini file match those
in the allocated memory. Otherwise, display errors may occur.
uc480 parameter files can also be created and edited manually. The following table shows the structure of the
parameter file. The entries in square brackets [] indicate sections. If a section does not exist in the ini file, the
corresponding camera parameters will not be modified when you load the file.
Hint
You can use wildcards in the ini file:
If you specify * as first character, then the highlighted characters will be interpreted in the camera name only, e.g.
*DCU224C. Thus this string applies for DCU223C and DCU224C.
Structure of a uc480 parameter file
Parameter
Description
Value range
Example
[Versions]
uc480_api.dll
File version of the uc480 API
-
4.00.0000
uc480_eth.sys
(Not applicable to DCx
Cameras)
-
4.00.0000
uc480_usb.sys
File version of the USB uc480
driver
-
4.00.0000
uc480_boot.sys
File version of the USB uc480
boot loader
-
4.00.0000
[Sensor]
Sensor
Full name of the camera model
-
DCC3240C
[Image size]
Image size settings
Start X
Start point (X coordinate) in AOI
mode
0...(max. width
*1
-Width)
100
Start Y
Start point (Y coordinate) in AOI
mode
0...(max. height
*1
-Height)
100
Start X absolute
Activate absolute AOI
positioning in the memory (see
is_AOI() )
0, 1
1
Start Y absolute
Activate absolute AOI
positioning in the memory (see
is_AOI() )
0, 1
1
Width
Width of the AOI
Sensor-dependent
*1
2460
Height
Height of the AOI
Sensor-dependent
*1
1820
Binning
Activate binning mode and
select factor
Sensor-dependent
*2
0
Subsampling
Activate subsampling mode and
select factor
Sensor-dependent
*2
0
[Scaler]
The internal image scaling is only supported by sensors of the DCC1240x /
DCC3240x camera series.
Mode
Enable/disable scaling
0 = Scaling off
1 = Scaling on
0
Factor
Scaling factor
292
159
159
