© 2013 Thorlabs GmbH
4 Programming (SDK)
235
4.3.36 is_GetCameraLUT
USB 3.0
USB 3.0
Syntax
INT is_GetCameraLUT (HIDS hCam,
UINT Mode, UINT NumberOfEntries,
double* pRed_Grey,
double* pGreen,
double* pBlue)
Description
is_GetCameraLUT() returns the current LUT values. Using the is_SetCameraLUT() function, you can select a
different LUT for the camera.
Note
The is_SetCameraLUT() function is only supported by DCC3240 cameras.
Input parameters
hCam
Camera handle
Mode
IS_GET_CAMERA_LUT_USER
Returns the LUT values set by the user without modifications.
IS_GET_CAMERA_LUT_COMPLETE
Returns the LUT values set by the user after the gamma, contrast
and brightness values have been taken into account.
NumberOfEntries
Number of the LUT values
IS_CAMERA_LUT_64
LUT with 64 values
pRed_Grey
Pointer to the array to which the red channel values or
the gray scale value of the LUT are written.
pGreen
Pointer to the array to which the green channel values
of the LUT are written.
pBlue
Pointer to the array to which the blue channel values
of the LUT are written.
Return values
IS_INVALID_CAMERA_HANDLE
Invalid camera handle
IS_NO_SUCCESS
General error message
IS_NOT_SUPPORTED
The camera model used here does not support this function or
setting.
IS_SUCCESS
Function executed successfully
