© 2013 Thorlabs GmbH
6 Appendix
509
Parameter
Description
Value range
Example
Flash delay
Delay of the flash signal in µs
Depends on sensor setting, can
be queried using is_IO()
0
Flash duration
Duration of the flash signal in µs
Depends on sensor setting, can
be queried using is_IO()
200
PWM mode
PWM mode
see is_IO()
PWM frequency
Frequency of the pulse-width
modulation
PWM duytcycle
Duty cycle of the pulse-width
modulation
0.0…1.0 (1.0 corresponds to
100 %)
GPIO state
State of the GPIO
see is_IO()
GPIO direction
Direction of the GPIO
see is_IO()
[Sequence AOI]
The sequence AOI is supported by DCC1240x / DCC3240x models only.
NumberUsedAOI
Number of used AOIs
see is_AOI()
StartX1…StartX3
X position of AOI 1-3
StartY1…StartY3
Y position of AOI 1-3
Gain1…Gain3
Gain of AOI 1-3
Exposure1…Exposure3
Exposure of AOI 1-3
ReadoutCycle1…
ReadoutCycle3
Number of read-out cycles of
AOI 1-3
BinningMode1…
BinningMode3
Binning mode of AOI 1-3
SubsamplingMode1…
SubsamplingMode3
Subsampling mode of AOI 1-3
ScalerFactor1…
ScalerFactor3
Scaling factor of AOI 1-3
DetachImageParameter1…
DetachImageParameter3
Changes of exposure time and
gain are transferred to AOI 1-3
0 = Every change is transferred
1 = Changes are not transferred
see also is_AOI()
[Transfer]
Not supported by DCx cameras
ImageDelay_us
PacketInterval_us
*
1
This information is provided in Camera and sensor data chapter.
*
2
For the parameters, please refer to the uc480.h header file provided in the \Develop\include folder of the uc480
installation directory (see also Programming notes ).
*
3
Function obsolete, see chapter Obsolete functions .
6.5 Definition of IP Protection Classes
The housing of the DCx Cameras comply with IP 30:
Protection against the ingression of small particles (diameter > 2.5 mm)
No protection against water
6.6 History of uc480 Software Versions
For new features in the current driver version 4.20see What is New in this Version? .
New in Version 4.02
Cameras & functions
Described in chapter
The USB 3 DCC3240x cameras are now supported under Windows
280
280
280
280
280
159
159
460
451
379
16
