© 2013 Thorlabs GmbH294
DCx Cameras
4.3.69 is_PixelClock
USB 2.0
USB 3.0
USB 2.0
USB 3.0
Syntax
INT is_PixelClock(HIDS hCam, UINT nCommand, void* pParam, UINT cbSizeOfParam)
Description
The function returns the adjustable pixel clock range sets the piel clock. Due to an excessive pixel clock for USB
cameras, images may get lost during the transfer. If you change the pixel clock on-the-fly, the current image
capturing process will be aborted.
The pixel clock limit values can vary, depending on the camera model and operating mode. For detailed
information on the pixel clock range of a specific camera model, please refer to the Camera and sensor data
chapter.
The nCommand input parameter is used to select the function mode. The pParam input parameter depends on the
selected function mode. If you select functions for setting or returning a value, pParam contains a pointer to a
variable of the UINT type. The size of the memory area to which pParam refers is specified in the
cbSizeOfParam input parameter.
Note
Note: The following functions are obsolete by the is_PixelClock() function:
is_SetPixelClock()
is_GetPixelClockRange()
See also: Obsolete functions
Input parameter
hCam
Camera handle
nCommand
IS_PIXELCLOCK_CMD_GET_NUMBER
Returns the number of discrete pixel clock which are
supported by the camera (Example 1 ).
IS_PIXELCLOCK_CMD_GET_LIST
Returns the list with discrete pixel clocks.
IS_PIXELCLOCK_CMD_GET_RANGE
Returns the range for the pixel clock (Example 2 )
IS_PIXELCLOCK_CMD_GET_DEFAULT
Returns the default pixel clock (Example 4 )
IS_PIXELCLOCK_CMD_GET
Returns the current set pixel clock in MHz (Example 3
)
IS_PIXELCLOCK_CMD_SET
Sets the pixel clock in MHz (Example 4 )
pParam
Pointer to a function parameter, whose function depends
on nCommand.
cbSizeOfParam
Size (in bytes) of the memory area to which pParam
refers.
Return values
IS_INVALID_MODE
Camera is in standby mode, function not allowed
IS_INVALID_PARAMETER
One of the submitted parameters is outside the valid
range or is not supported for this sensor or is not
available in this mode.
IS_NO_SUCCESS
General error message
IS_NOT_SUPPORTED
The camera model used here does not support this
function or setting.
IS_SUCCESS
Function executed successfully
460
379
295
295
295
295
295
