© 2013 Thorlabs GmbH228
DCx Cameras
below.
DWORD
reserved[8]
Reserved space for extensions
Contents of the UC480_AUTO_INFO::AUTO_BRIGHT_STATUS Structure
INT
curValue
Current average brightness of the image (actual value); the
following rule applies independently of the image bit depth:
0 = black
255 = white
INT
curError
Current control deviation (error)
INT
curController
Current parameter value
AC_SHUTTER
Exposure time (shutter)
AC_GAIN
Gain
INT
curCtrlStatus
Current control status
ACS_ADJUSTING
Control is active.
ACS_FINISHED
Control is completed.
ACS_DISABLED
Control is disabled.
Contents of the UC480_AUTO_INFO::AUTO_WB_STATUS Structure
INT
curController
Current white balance control
AC_WB_RED_CHANNEL
Value of the red channel
AC_WB_GREEN_CHANNEL
Value of the green channel
AC_WB_BLUE_CHANNEL
Value of the blue channel
AUTO_WB_CHANNEL_STATUS
RedChannel
See AUTO_WB_CHANNEL_STATUS
AUTO_WB_CHANNEL_STATUS
GreenChannel
See AUTO_WB_CHANNEL_STATUS
AUTO_WB_CHANNEL_STATUS
BlueChannel
See AUTO_WB_CHANNEL_STATUS
Contents of the UC480_AUTO_INFO::AUTO_WB_STATUS::AUTO_WB_CHANNEL_STATUS Structure
INT
curValue
Current average grayscale value (actual value)
INT
curError
Current control deviation (error)
INT
curCtrlStatus
Current control status
ACS_ADJUSTING
Control is active.
ACS_FINISHED
Control is completed.
ACS_DISABLED
Control is disabled.
Status Flags in UC480_AUTO_INFO::AShutterPhotomCaps
AS_PM_NONE
The entire field of view is used for metering.
AS_PM_SENS_CENTER_WEIGHTED
Metering is based on the entire field of view, but gives
greater emphasis to the center area of the image.
AS_PM_SENS_CENTER_SPOT
Only a small area in the image center is used for
metering.
AS_PM_SENS_PORTRAIT
Metering is based on that part of the field of view that
corresponds to the portrait format.
AS_PM_SENS_LANDSCAPE
Metering is based on that part of the field of view that
corresponds to the landscape format.
Status Flags in UC480_AUTO_INFO::AGainPhotomCaps
AG_PM_NONE
The entire field of view is used for metering.
AG_PM_SENS_CENTER_WEIGHTED
Metering is based on the entire field of view, but gives
greater emphasis to the center area of the image.
