© 2013 Thorlabs GmbH268
DCx Cameras
hCam
Camera handle
nSizeOfParam
Size (in bytes) of the memory area to which pParam
refers.
Contents of the IMAGE_FORMAT_LIST list of image formats
UINT
nSizeOfListEntry
Must be preset with the size of a list entry in bytes
UINT
nNumListElements
Must be preset with the number of list entries (from
IMGFRMT_CMD_GET_NUM_ENTRIES)
UINT
nReserved[4]
Reserved
IMAGE_FORMAT_INF
O
FormatInfo[0]
First entry in the list.
After having been filled by IMGFRMT_CMD_GET_LIST, the list
contains additional entries FormatInfo[1]…FormatInfo
[nNumListElements-1].
Contents of the list entry IMAGE_FORMAT_INFO
INT
nFormatID
Format ID of the specified image format (see table "Image
formats" below)
UINT
nWidth
Width of the area of interest
UINT
nHeight
Height of the area of interest
UINT
nX0
Start point of the area of interest (X)
UINT
nY0
Start point of the area of interest (Y)
UINT
nSupportedCaptureModes
Image capture modes supported for this format (see table
below)
UINT
nBinningMode
Binning mode used
UINT
nSubsamplingMode
Subsampling mode used
IS_CHAR
strFormatName[64]
Description of the format
double
dSensorScalerFactor
Scaling factor used (only sensors that support scaling ).
UINT
nReserved[24]
Reserved
Possible values for CAPTUREMODE
CAPTMODE_SINGLE
Freerun mode, single frame (freerun snap)
CAPTMODE_FREERUN
Freerun mode, continuous (freerun live)
CAPTMODE_TRIGGER_SOFT_SINGLE
Software triggered mode, single frame
CAPTMODE_TRIGGER_SOFT_CONTINUOUS
Software triggered mode, continuous
CAPTMODE_TRIGGER_HW_SINGLE
Hardware triggered mode, single frame
CAPTMODE_TRIGGER_HW_CONTINUOUS
Hardware triggered mode, continuous
For further information on the image capture modes, see also in the Basics: Operating modes chapter.
