THORLABS PM100D User Manual

1.2 Ordering Codes and Accessories
Pyroelectric Energy Sensors:
Order Code Type Aperture
mm
Wavelength
nm
Energy
J
ES111C Pyroelectric Sensor with
broadband coating
∅ 11
185 - 25000 10µ - 150m
ES120C Pyroelectric Sensor with
broadband coating
∅ 20
185 - 25000 100µ - 500m
ES145C Pyroelectric Sensor with
broadband coating
∅ 45
185 - 25000 500µ - 2
ES220C Pyroelectric Sensor with
ceramic coating
∅ 20
185 - 25000 500µ - 3
ES245C Pyroelectric Sensor with
ceramic coating
∅ 45
185 - 25000 1m -15
Please visit our homepage http://www.thorlabs.com for various accessories like fiber
adapters, posts and post-holders, data sheets and further information.
8

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
