THORLABS PM100D User Manual

1.1 Safety
1.1 Safety
 Attention 
All statements regarding safety of operation and technical data in this
instruction manual will only apply when the unit is operated correctly.
The power meter PM100D must not be operated in explosion endan-
gered environments!
Sensor, photodiode and control inputs and outputs must only be
connected with duly shielded connection cables.
Only with written consent from Thorlabs may changes to single compo-
nents be carried out or components not supplied by Thorlabs be used.
Do not remove covers!
Refer servicing to qualified personal!
 Attention 
Mobile telephones, cellular phones or other radio transmitters are
not to be used within the range of three meters of this unit since the
electromagnetic field intensity may then exceed the maximum
allowed disturbance values according to IEC 61326-1.
This product has been tested and found to comply with the limits
according to IEC 61326-1 for using connection cables shorter than 3
meters (9.8 feet).
5

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
